| TMS4-440-.312-P | Inch | 4-40 | .312 | .040 | .166 | .23 | HRB 88 or less | .165 | .187 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-440-.375-P | Inch | 4-40 | .375 | .040 | .166 | .23 | HRB 88 or less | .165 | .187 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-440-.437-P | Inch | 4-40 | .437 | .040 | .166 | .23 | HRB 88 or less | .165 | .187 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-440-.500-P | Inch | 4-40 | .500 | .040 | .166 | .23 | HRB 88 or less | .165 | .187 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-440-.562-P | Inch | 4-40 | .562 | .040 | .166 | .23 | HRB 88 or less | .165 | .187 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-440-.625-P | Inch | 4-40 | .625 | .040 | .166 | .23 | HRB 88 or less | .165 | .187 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-440-.687-P | Inch | 4-40 | .687 | .040 | .166 | .23 | HRB 88 or less | .165 | .187 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-440-.750-P | Inch | 4-40 | .750 | .040 | .166 | .23 | HRB 88 or less | .165 | .187 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-440-.812-P | Inch | 4-40 | .812 | .040 | .166 | .23 | HRB 88 or less | .165 | .187 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-440-.875-P | Inch | 4-40 | .875 | .040 | .166 | .23 | HRB 88 or less | .165 | .187 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-440-.937-P | Inch | 4-40 | .937 | .040 | .166 | .23 | HRB 88 or less | .165 | .187 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-440-1.000-P | Inch | 4-40 | 1.000 | .040 | .166 | .23 | HRB 88 or less | .165 | .187 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-440-1.062-P | Inch | 4-40 | 1.062 | .040 | .213 | .27 | HRB 88 or less | .165 | .187 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-6440-.312-P | Inch | 4-40 | .312 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-6440-.375-P | Inch | 4-40 | .375 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-6440-.437-P | Inch | 4-40 | .437 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-6440-.500-P | Inch | 4-40 | .500 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-6440-.562-P | Inch | 4-40 | .562 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-6440-.625-P | Inch | 4-40 | .625 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-6440-.687-P | Inch | 4-40 | .687 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-6440-.750-P | Inch | 4-40 | .750 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-6440-.812-P | Inch | 4-40 | .812 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-6440-.875-P | Inch | 4-40 | .875 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-6440-.937-P | Inch | 4-40 | .937 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-6440-1.000-P | Inch | 4-40 | 1.000 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-6440-1.062-P | Inch | 4-40 | 1.062 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMST-440-.312-Z | Inch | 4-40 | .312 | .040 | .166 | .23 | HRB 80 or less | .165 | .187 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-440-.375-Z | Inch | 4-40 | .375 | .040 | .166 | .23 | HRB 80 or less | .165 | .187 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-440-.437-Z | Inch | 4-40 | .437 | .040 | .166 | .23 | HRB 80 or less | .165 | .187 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-440-.500-Z | Inch | 4-40 | .500 | .040 | .166 | .23 | HRB 80 or less | .165 | .187 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-440-.562-Z | Inch | 4-40 | .562 | .040 | .166 | .23 | HRB 80 or less | .165 | .187 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-440-.625-Z | Inch | 4-40 | .625 | .040 | .166 | .23 | HRB 80 or less | .165 | .187 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-440-.687-Z | Inch | 4-40 | .687 | .040 | .166 | .23 | HRB 80 or less | .165 | .187 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-440-.750-Z | Inch | 4-40 | .750 | .040 | .166 | .23 | HRB 80 or less | .165 | .187 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-440-.812-Z | Inch | 4-40 | .812 | .040 | .166 | .23 | HRB 80 or less | .165 | .187 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-440-.875-Z | Inch | 4-40 | .875 | .040 | .166 | .23 | HRB 80 or less | .165 | .187 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-440-.937-Z | Inch | 4-40 | .937 | .040 | .166 | .23 | HRB 80 or less | .165 | .187 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-440-1.000-Z | Inch | 4-40 | 1.000 | .040 | .166 | .23 | HRB 80 or less | .165 | .187 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-440-1.062-Z | Inch | 4-40 | 1.062 | .040 | .213 | .27 | HRB 80 or less | .165 | .187 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-6440-.312-Z | Inch | 4-40 | .312 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-6440-.375-Z | Inch | 4-40 | .375 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-6440-.437-Z | Inch | 4-40 | .437 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-6440-.500-Z | Inch | 4-40 | .500 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-6440-.562-Z | Inch | 4-40 | .562 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-6440-.625-Z | Inch | 4-40 | .625 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-6440-.687-Z | Inch | 4-40 | .687 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-6440-.750-Z | Inch | 4-40 | .750 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-6440-.812-Z | Inch | 4-40 | .812 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-6440-.875-Z | Inch | 4-40 | .875 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-6440-.937-Z | Inch | 4-40 | .937 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-6440-1.000-Z | Inch | 4-40 | 1.000 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-6440-1.062-Z | Inch | 4-40 | 1.062 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMSS-440-.312-P | Inch | 4-40 | .312 | .040 | .166 | .23 | HRB 70 or less | .165 | .187 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-440-.375-P | Inch | 4-40 | .375 | .040 | .166 | .23 | HRB 70 or less | .165 | .187 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-440-.437-P | Inch | 4-40 | .437 | .040 | .166 | .23 | HRB 70 or less | .165 | .187 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-440-.500-P | Inch | 4-40 | .500 | .040 | .166 | .23 | HRB 70 or less | .165 | .187 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-440-.562-P | Inch | 4-40 | .562 | .040 | .166 | .23 | HRB 70 or less | .165 | .187 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-440-.625-P | Inch | 4-40 | .625 | .040 | .166 | .23 | HRB 70 or less | .165 | .187 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-440-.687-P | Inch | 4-40 | .687 | .040 | .166 | .23 | HRB 70 or less | .165 | .187 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-440-.750-P | Inch | 4-40 | .750 | .040 | .166 | .23 | HRB 70 or less | .165 | .187 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-440-.812-P | Inch | 4-40 | .812 | .040 | .166 | .23 | HRB 70 or less | .165 | .187 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-440-.875-P | Inch | 4-40 | .875 | .040 | .166 | .23 | HRB 70 or less | .165 | .187 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-440-.937-P | Inch | 4-40 | .937 | .040 | .166 | .23 | HRB 70 or less | .165 | .187 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-440-1.000-P | Inch | 4-40 | 1.000 | .040 | .166 | .23 | HRB 70 or less | .165 | .187 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-440-1.062-P | Inch | 4-40 | 1.062 | .040 | .213 | .27 | HRB 70 or less | .165 | .187 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-6440-.312-P | Inch | 4-40 | .312 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-6440-.375-P | Inch | 4-40 | .375 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-6440-.437-P | Inch | 4-40 | .437 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-6440-.500-P | Inch | 4-40 | .500 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-6440-.562-P | Inch | 4-40 | .562 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-6440-.625-P | Inch | 4-40 | .625 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-6440-.687-P | Inch | 4-40 | .687 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-6440-.750-P | Inch | 4-40 | .750 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-6440-.812-P | Inch | 4-40 | .812 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-6440-.875-P | Inch | 4-40 | .875 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-6440-.937-P | Inch | 4-40 | .937 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-6440-1.000-P | Inch | 4-40 | 1.000 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-6440-1.062-P | Inch | 4-40 | 1.062 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMAL-440-.312-PLN | Inch | 4-40 | .312 | .040 | .166 | .23 | HRB 50 or less | .165 | .187 | Aluminum | Clean and dry |
| TMAL-440-.375-PLN | Inch | 4-40 | .375 | .040 | .166 | .23 | HRB 50 or less | .165 | .187 | Aluminum | Clean and dry |
| TMAL-440-.437-PLN | Inch | 4-40 | .437 | .040 | .166 | .23 | HRB 50 or less | .165 | .187 | Aluminum | Clean and dry |
| TMAL-440-.500-PLN | Inch | 4-40 | .500 | .040 | .166 | .23 | HRB 50 or less | .165 | .187 | Aluminum | Clean and dry |
| TMAL-440-.562-PLN | Inch | 4-40 | .562 | .040 | .166 | .23 | HRB 50 or less | .165 | .187 | Aluminum | Clean and dry |
| TMAL-440-.625-PLN | Inch | 4-40 | .625 | .040 | .166 | .23 | HRB 50 or less | .165 | .187 | Aluminum | Clean and dry |
| TMAL-440-.687-PLN | Inch | 4-40 | .687 | .040 | .166 | .23 | HRB 50 or less | .165 | .187 | Aluminum | Clean and dry |
| TMAL-440-.750-PLN | Inch | 4-40 | .750 | .040 | .166 | .23 | HRB 50 or less | .165 | .187 | Aluminum | Clean and dry |
| TMAL-440-.812-PLN | Inch | 4-40 | .812 | .040 | .166 | .23 | HRB 50 or less | .165 | .187 | Aluminum | Clean and dry |
| TMAL-440-.875-PLN | Inch | 4-40 | .875 | .040 | .166 | .23 | HRB 50 or less | .165 | .187 | Aluminum | Clean and dry |
| TMAL-440-.937-PLN | Inch | 4-40 | .937 | .040 | .166 | .23 | HRB 50 or less | .165 | .187 | Aluminum | Clean and dry |
| TMAL-440-1.000-PLN | Inch | 4-40 | 1.000 | .040 | .166 | .23 | HRB 50 or less | .165 | .187 | Aluminum | Clean and dry |
| TMAL-440-1.062-PLN | Inch | 4-40 | 1.062 | .040 | .213 | .27 | HRB 50 or less | .165 | .187 | Aluminum | Clean and dry |
| TMAL-6440-.312-PLN | Inch | 4-40 | .312 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-6440-.375-PLN | Inch | 4-40 | .375 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-6440-.437-PLN | Inch | 4-40 | .437 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-6440-.500-PLN | Inch | 4-40 | .500 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-6440-.562-PLN | Inch | 4-40 | .562 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-6440-.625-PLN | Inch | 4-40 | .625 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-6440-.687-PLN | Inch | 4-40 | .687 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-6440-.750-PLN | Inch | 4-40 | .750 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-6440-.812-PLN | Inch | 4-40 | .812 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-6440-.875-PLN | Inch | 4-40 | .875 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-6440-.937-PLN | Inch | 4-40 | .937 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-6440-1.000-PLN | Inch | 4-40 | 1.000 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-6440-1.062-PLN | Inch | 4-40 | 1.062 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMS4-632-.312-P | Inch | 6-32 | .312 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-632-.375-P | Inch | 6-32 | .375 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-632-.437-P | Inch | 6-32 | .437 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-632-.500-P | Inch | 6-32 | .500 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-632-.562-P | Inch | 6-32 | .562 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-632-.625-P | Inch | 6-32 | .625 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-632-.687-P | Inch | 6-32 | .687 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-632-.750-P | Inch | 6-32 | .750 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-632-.812-P | Inch | 6-32 | .812 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-632-.875-P | Inch | 6-32 | .875 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-632-.937-P | Inch | 6-32 | .937 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-632-1.000-P | Inch | 6-32 | 1.000 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-632-1.062-P | Inch | 6-32 | 1.062 | .040 | .213 | .27 | HRB 88 or less | .212 | .250 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-8632-.312-P | Inch | 6-32 | .312 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-8632-.375-P | Inch | 6-32 | .375 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-8632-.437-P | Inch | 6-32 | .437 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-8632-.500-P | Inch | 6-32 | .500 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-8632-.562-P | Inch | 6-32 | .562 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-8632-.625-P | Inch | 6-32 | .625 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-8632-.687-P | Inch | 6-32 | .687 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-8632-.750-P | Inch | 6-32 | .750 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-8632-.812-P | Inch | 6-32 | .812 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-8632-.875-P | Inch | 6-32 | .875 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-8632-.937-P | Inch | 6-32 | .937 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-8632-1.000-P | Inch | 6-32 | 1.000 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-8632-1.062-P | Inch | 6-32 | 1.062 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMST-632-.312-Z | Inch | 6-32 | .312 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-632-.375-Z | Inch | 6-32 | .375 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-632-.437-Z | Inch | 6-32 | .437 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-632-.500-Z | Inch | 6-32 | .500 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-632-.562-Z | Inch | 6-32 | .562 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-632-.625-Z | Inch | 6-32 | .625 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-632-.687-Z | Inch | 6-32 | .687 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-632-.750-Z | Inch | 6-32 | .750 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-632-.812-Z | Inch | 6-32 | .812 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-632-.875-Z | Inch | 6-32 | .875 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-632-.937-Z | Inch | 6-32 | .937 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-632-1.000-Z | Inch | 6-32 | 1.000 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-632-1.062-Z | Inch | 6-32 | 1.062 | .040 | .213 | .27 | HRB 80 or less | .212 | .250 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-8632-.312-Z | Inch | 6-32 | .312 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-8632-.375-Z | Inch | 6-32 | .375 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-8632-.437-Z | Inch | 6-32 | .437 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-8632-.500-Z | Inch | 6-32 | .500 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-8632-.562-Z | Inch | 6-32 | .562 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-8632-.625-Z | Inch | 6-32 | .625 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-8632-.687-Z | Inch | 6-32 | .687 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-8632-.750-Z | Inch | 6-32 | .750 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-8632-.812-Z | Inch | 6-32 | .812 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-8632-.875-Z | Inch | 6-32 | .875 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-8632-.937-Z | Inch | 6-32 | .937 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-8632-1.000-Z | Inch | 6-32 | 1.000 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-8632-1.062-Z | Inch | 6-32 | 1.062 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMSS-632-.312-P | Inch | 6-32 | .312 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-632-.375-P | Inch | 6-32 | .375 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-632-.437-P | Inch | 6-32 | .437 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-632-.500-P | Inch | 6-32 | .500 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-632-.562-P | Inch | 6-32 | .562 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-632-.625-P | Inch | 6-32 | .625 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-632-.687-P | Inch | 6-32 | .687 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-632-.750-P | Inch | 6-32 | .750 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-632-.812-P | Inch | 6-32 | .812 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-632-.875-P | Inch | 6-32 | .875 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-632-.937-P | Inch | 6-32 | .937 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-632-1.000-P | Inch | 6-32 | 1.000 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-632-1.062-P | Inch | 6-32 | 1.062 | .040 | .213 | .27 | HRB 70 or less | .212 | .250 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-8632-.312-P | Inch | 6-32 | .312 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-8632-.375-P | Inch | 6-32 | .375 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-8632-.437-P | Inch | 6-32 | .437 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-8632-.500-P | Inch | 6-32 | .500 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-8632-.562-P | Inch | 6-32 | .562 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-8632-.625-P | Inch | 6-32 | .625 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-8632-.687-P | Inch | 6-32 | .687 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-8632-.750-P | Inch | 6-32 | .750 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-8632-.812-P | Inch | 6-32 | .812 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-8632-.875-P | Inch | 6-32 | .875 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-8632-.937-P | Inch | 6-32 | .937 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-8632-1.000-P | Inch | 6-32 | 1.000 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-8632-1.062-P | Inch | 6-32 | 1.062 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMAL-632-.312-PLN | Inch | 6-32 | .312 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-632-.375-PLN | Inch | 6-32 | .375 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-632-.437-PLN | Inch | 6-32 | .437 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-632-.500-PLN | Inch | 6-32 | .500 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-632-.562-PLN | Inch | 6-32 | .562 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-632-.625-PLN | Inch | 6-32 | .625 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-632-.687-PLN | Inch | 6-32 | .687 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-632-.750-PLN | Inch | 6-32 | .750 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-632-.812-PLN | Inch | 6-32 | .812 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-632-.875-PLN | Inch | 6-32 | .875 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-632-.937-PLN | Inch | 6-32 | .937 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-632-1.000-PLN | Inch | 6-32 | 1.000 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-632-1.062-PLN | Inch | 6-32 | 1.062 | .040 | .213 | .27 | HRB 50 or less | .212 | .250 | Aluminum | Clean and dry |
| TMAL-8632-.312-PLN | Inch | 6-32 | .312 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-8632-.375-PLN | Inch | 6-32 | .375 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-8632-.437-PLN | Inch | 6-32 | .437 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-8632-.500-PLN | Inch | 6-32 | .500 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-8632-.562-PLN | Inch | 6-32 | .562 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-8632-.625-PLN | Inch | 6-32 | .625 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-8632-.687-PLN | Inch | 6-32 | .687 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-8632-.750-PLN | Inch | 6-32 | .750 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-8632-.812-PLN | Inch | 6-32 | .812 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-8632-.875-PLN | Inch | 6-32 | .875 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-8632-.937-PLN | Inch | 6-32 | .937 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-8632-1.000-PLN | Inch | 6-32 | 1.000 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-8632-1.062-PLN | Inch | 6-32 | 1.062 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMS4-832-.312-P | Inch | 8-32 | .312 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-832-.375-P | Inch | 8-32 | .375 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-832-.437-P | Inch | 8-32 | .437 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-832-.500-P | Inch | 8-32 | .500 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-832-.562-P | Inch | 8-32 | .562 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-832-.625-P | Inch | 8-32 | .625 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-832-.687-P | Inch | 8-32 | .687 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-832-.750-P | Inch | 8-32 | .750 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-832-.812-P | Inch | 8-32 | .812 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-832-.875-P | Inch | 8-32 | .875 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-832-.937-P | Inch | 8-32 | .937 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-832-1.000-P | Inch | 8-32 | 1.000 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-832-1.062-P | Inch | 8-32 | 1.062 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMST-832-.312-Z | Inch | 8-32 | .312 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-832-.375-Z | Inch | 8-32 | .375 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-832-.437-Z | Inch | 8-32 | .437 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-832-.500-Z | Inch | 8-32 | .500 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-832-.562-Z | Inch | 8-32 | .562 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-832-.625-Z | Inch | 8-32 | .625 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-832-.687-Z | Inch | 8-32 | .687 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-832-.750-Z | Inch | 8-32 | .750 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-832-.812-Z | Inch | 8-32 | .812 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-832-.875-Z | Inch | 8-32 | .875 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-832-.937-Z | Inch | 8-32 | .937 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-832-1.000-Z | Inch | 8-32 | 1.000 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-832-1.062-Z | Inch | 8-32 | 1.062 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMSS-832-.312-P | Inch | 8-32 | .312 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-832-.375-P | Inch | 8-32 | .375 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-832-.437-P | Inch | 8-32 | .437 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-832-.500-P | Inch | 8-32 | .500 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-832-.562-P | Inch | 8-32 | .562 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-832-.625-P | Inch | 8-32 | .625 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-832-.687-P | Inch | 8-32 | .687 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-832-.750-P | Inch | 8-32 | .750 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-832-.812-P | Inch | 8-32 | .812 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-832-.875-P | Inch | 8-32 | .875 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-832-.937-P | Inch | 8-32 | .937 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-832-1.000-P | Inch | 8-32 | 1.000 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-832-1.062-P | Inch | 8-32 | 1.062 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMAL-832-.312-PLN | Inch | 8-32 | .312 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-832-.375-PLN | Inch | 8-32 | .375 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-832-.437-PLN | Inch | 8-32 | .437 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-832-.500-PLN | Inch | 8-32 | .500 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-832-.562-PLN | Inch | 8-32 | .562 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-832-.625-PLN | Inch | 8-32 | .625 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-832-.687-PLN | Inch | 8-32 | .687 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-832-.750-PLN | Inch | 8-32 | .750 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-832-.812-PLN | Inch | 8-32 | .812 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-832-.875-PLN | Inch | 8-32 | .875 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-832-.937-PLN | Inch | 8-32 | .937 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-832-1.000-PLN | Inch | 8-32 | 1.000 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-832-1.062-PLN | Inch | 8-32 | 1.062 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMS4-1032-.312-P | Inch | 10-32 | .312 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-1032-.375-P | Inch | 10-32 | .375 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-1032-.437-P | Inch | 10-32 | .437 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-1032-.500-P | Inch | 10-32 | .500 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-1032-.562-P | Inch | 10-32 | .562 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-1032-.625-P | Inch | 10-32 | .625 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-1032-.687-P | Inch | 10-32 | .687 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-1032-.750-P | Inch | 10-32 | .750 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-1032-.812-P | Inch | 10-32 | .812 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-1032-.875-P | Inch | 10-32 | .875 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-1032-.937-P | Inch | 10-32 | .937 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-1032-1.000-P | Inch | 10-32 | 1.000 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-1032-1.062-P | Inch | 10-32 | 1.062 | .050 | .281 | .31 | HRB 88 or less | .280 | .312 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMST-1032-.312-Z | Inch | 10-32 | .312 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-1032-.375-Z | Inch | 10-32 | .375 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-1032-.437-Z | Inch | 10-32 | .437 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-1032-.500-Z | Inch | 10-32 | .500 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-1032-.562-Z | Inch | 10-32 | .562 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-1032-.625-Z | Inch | 10-32 | .625 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-1032-.687-Z | Inch | 10-32 | .687 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-1032-.750-Z | Inch | 10-32 | .750 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-1032-.812-Z | Inch | 10-32 | .812 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-1032-.875-Z | Inch | 10-32 | .875 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-1032-.937-Z | Inch | 10-32 | .937 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-1032-1.000-Z | Inch | 10-32 | 1.000 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-1032-1.062-Z | Inch | 10-32 | 1.062 | .050 | .281 | .31 | HRB 80 or less | .280 | .312 | Heat treated carbon steel | Zinc with clear chromate |
| TMSS-1032-.312-P | Inch | 10-32 | .312 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-1032-.375-P | Inch | 10-32 | .375 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-1032-.437-P | Inch | 10-32 | .437 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-1032-.500-P | Inch | 10-32 | .500 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-1032-.562-P | Inch | 10-32 | .562 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-1032-.625-P | Inch | 10-32 | .625 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-1032-.687-P | Inch | 10-32 | .687 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-1032-.750-P | Inch | 10-32 | .750 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-1032-.812-P | Inch | 10-32 | .812 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-1032-.875-P | Inch | 10-32 | .875 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-1032-.937-P | Inch | 10-32 | .937 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-1032-1.000-P | Inch | 10-32 | 1.000 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-1032-1.062-P | Inch | 10-32 | 1.062 | .050 | .281 | .31 | HRB 70 or less | .280 | .312 | 300-Series stainless steel | Passivated and/or tested |
| TMAL-1032-.312-PLN | Inch | 10-32 | .312 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-1032-.375-PLN | Inch | 10-32 | .375 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-1032-.437-PLN | Inch | 10-32 | .437 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-1032-.500-PLN | Inch | 10-32 | .500 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-1032-.562-PLN | Inch | 10-32 | .562 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-1032-.625-PLN | Inch | 10-32 | .625 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-1032-.687-PLN | Inch | 10-32 | .687 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-1032-.750-PLN | Inch | 10-32 | .750 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-1032-.812-PLN | Inch | 10-32 | .812 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-1032-.875-PLN | Inch | 10-32 | .875 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-1032-.937-PLN | Inch | 10-32 | .937 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-1032-1.000-PLN | Inch | 10-32 | 1.000 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMAL-1032-1.062-PLN | Inch | 10-32 | 1.062 | .050 | .281 | .31 | HRB 50 or less | .280 | .312 | Aluminum | Clean and dry |
| TMS4-M3-6-P | Metric | M3 x 0.5 | 6 | 1.00 | 4.22 | 6.0 | HRB 88 or less | 4.20 | 4.8 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M3-8-P | Metric | M3 x 0.5 | 8 | 1.00 | 4.22 | 6.0 | HRB 88 or less | 4.20 | 4.8 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M3-10-P | Metric | M3 x 0.5 | 10 | 1.00 | 4.22 | 6.0 | HRB 88 or less | 4.20 | 4.8 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M3-12-P | Metric | M3 x 0.5 | 12 | 1.00 | 4.22 | 6.0 | HRB 88 or less | 4.20 | 4.8 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M3-14-P | Metric | M3 x 0.5 | 14 | 1.00 | 4.22 | 6.0 | HRB 88 or less | 4.20 | 4.8 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M3-16-P | Metric | M3 x 0.5 | 16 | 1.00 | 4.22 | 6.0 | HRB 88 or less | 4.20 | 4.8 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M3-18-P | Metric | M3 x 0.5 | 18 | 1.00 | 4.22 | 6.0 | HRB 88 or less | 4.20 | 4.8 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M3-20-P | Metric | M3 x 0.5 | 20 | 1.00 | 4.22 | 6.0 | HRB 88 or less | 4.20 | 4.8 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M3-22-P | Metric | M3 x 0.5 | 22 | 1.00 | 4.22 | 6.0 | HRB 88 or less | 4.20 | 4.8 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M3-25-P | Metric | M3 x 0.5 | 25 | 1.00 | 4.22 | 6.0 | HRB 88 or less | 4.20 | 4.8 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-3.5M3-6-P | Metric | M3 x 0.5 | 6 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-3.5M3-8-P | Metric | M3 x 0.5 | 8 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-3.5M3-10-P | Metric | M3 x 0.5 | 10 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-3.5M3-12-P | Metric | M3 x 0.5 | 12 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-3.5M3-14-P | Metric | M3 x 0.5 | 14 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-3.5M3-16-P | Metric | M3 x 0.5 | 16 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-3.5M3-18-P | Metric | M3 x 0.5 | 18 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-3.5M3-20-P | Metric | M3 x 0.5 | 20 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-3.5M3-22-P | Metric | M3 x 0.5 | 22 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-3.5M3-25-P | Metric | M3 x 0.5 | 25 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMST-M3-6-Z | Metric | M3 x 0.5 | 6 | 1.00 | 4.22 | 6.0 | HRB 80 or less | 4.20 | 4.8 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M3-8-Z | Metric | M3 x 0.5 | 8 | 1.00 | 4.22 | 6.0 | HRB 80 or less | 4.20 | 4.8 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M3-10-Z | Metric | M3 x 0.5 | 10 | 1.00 | 4.22 | 6.0 | HRB 80 or less | 4.20 | 4.8 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M3-12-Z | Metric | M3 x 0.5 | 12 | 1.00 | 4.22 | 6.0 | HRB 80 or less | 4.20 | 4.8 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M3-14-Z | Metric | M3 x 0.5 | 14 | 1.00 | 4.22 | 6.0 | HRB 80 or less | 4.20 | 4.8 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M3-16-Z | Metric | M3 x 0.5 | 16 | 1.00 | 4.22 | 6.0 | HRB 80 or less | 4.20 | 4.8 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M3-18-Z | Metric | M3 x 0.5 | 18 | 1.00 | 4.22 | 6.0 | HRB 80 or less | 4.20 | 4.8 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M3-20-Z | Metric | M3 x 0.5 | 20 | 1.00 | 4.22 | 6.0 | HRB 80 or less | 4.20 | 4.8 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M3-22-Z | Metric | M3 x 0.5 | 22 | 1.00 | 4.22 | 6.0 | HRB 80 or less | 4.20 | 4.8 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M3-25-Z | Metric | M3 x 0.5 | 25 | 1.00 | 4.22 | 6.0 | HRB 80 or less | 4.20 | 4.8 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-3.5M3-6-Z | Metric | M3 x 0.5 | 6 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-3.5M3-8-Z | Metric | M3 x 0.5 | 8 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-3.5M3-10-Z | Metric | M3 x 0.5 | 10 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-3.5M3-12-Z | Metric | M3 x 0.5 | 12 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-3.5M3-14-Z | Metric | M3 x 0.5 | 14 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-3.5M3-16-Z | Metric | M3 x 0.5 | 16 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-3.5M3-18-Z | Metric | M3 x 0.5 | 18 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-3.5M3-20-Z | Metric | M3 x 0.5 | 20 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-3.5M3-22-Z | Metric | M3 x 0.5 | 22 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-3.5M3-25-Z | Metric | M3 x 0.5 | 25 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMSS-M3-6-P | Metric | M3 x 0.5 | 6 | 1.00 | 4.22 | 6.0 | HRB 70 or less | 4.20 | 4.8 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M3-8-P | Metric | M3 x 0.5 | 8 | 1.00 | 4.22 | 6.0 | HRB 70 or less | 4.20 | 4.8 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M3-10-P | Metric | M3 x 0.5 | 10 | 1.00 | 4.22 | 6.0 | HRB 70 or less | 4.20 | 4.8 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M3-12-P | Metric | M3 x 0.5 | 12 | 1.00 | 4.22 | 6.0 | HRB 70 or less | 4.20 | 4.8 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M3-14-P | Metric | M3 x 0.5 | 14 | 1.00 | 4.22 | 6.0 | HRB 70 or less | 4.20 | 4.8 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M3-16-P | Metric | M3 x 0.5 | 16 | 1.00 | 4.22 | 6.0 | HRB 70 or less | 4.20 | 4.8 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M3-18-P | Metric | M3 x 0.5 | 18 | 1.00 | 4.22 | 6.0 | HRB 70 or less | 4.20 | 4.8 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M3-20-P | Metric | M3 x 0.5 | 20 | 1.00 | 4.22 | 6.0 | HRB 70 or less | 4.20 | 4.8 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M3-22-P | Metric | M3 x 0.5 | 22 | 1.00 | 4.22 | 6.0 | HRB 70 or less | 4.20 | 4.8 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M3-25-P | Metric | M3 x 0.5 | 25 | 1.00 | 4.22 | 6.0 | HRB 70 or less | 4.20 | 4.8 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-3.5M3-6-P | Metric | M3 x 0.5 | 6 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-3.5M3-8-P | Metric | M3 x 0.5 | 8 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-3.5M3-10-P | Metric | M3 x 0.5 | 10 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-3.5M3-12-P | Metric | M3 x 0.5 | 12 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-3.5M3-14-P | Metric | M3 x 0.5 | 14 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-3.5M3-16-P | Metric | M3 x 0.5 | 16 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-3.5M3-18-P | Metric | M3 x 0.5 | 18 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-3.5M3-20-P | Metric | M3 x 0.5 | 20 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-3.5M3-22-P | Metric | M3 x 0.5 | 22 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-3.5M3-25-P | Metric | M3 x 0.5 | 25 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMAL-M3-6-PLN | Metric | M3 x 0.5 | 6 | 1.00 | 4.22 | 6.0 | HRB 50 or less | 4.20 | 4.8 | Aluminum | Clean and dry |
| TMAL-M3-8-PLN | Metric | M3 x 0.5 | 8 | 1.00 | 4.22 | 6.0 | HRB 50 or less | 4.20 | 4.8 | Aluminum | Clean and dry |
| TMAL-M3-10-PLN | Metric | M3 x 0.5 | 10 | 1.00 | 4.22 | 6.0 | HRB 50 or less | 4.20 | 4.8 | Aluminum | Clean and dry |
| TMAL-M3-12-PLN | Metric | M3 x 0.5 | 12 | 1.00 | 4.22 | 6.0 | HRB 50 or less | 4.20 | 4.8 | Aluminum | Clean and dry |
| TMAL-M3-14-PLN | Metric | M3 x 0.5 | 14 | 1.00 | 4.22 | 6.0 | HRB 50 or less | 4.20 | 4.8 | Aluminum | Clean and dry |
| TMAL-M3-16-PLN | Metric | M3 x 0.5 | 16 | 1.00 | 4.22 | 6.0 | HRB 50 or less | 4.20 | 4.8 | Aluminum | Clean and dry |
| TMAL-M3-18-PLN | Metric | M3 x 0.5 | 18 | 1.00 | 4.22 | 6.0 | HRB 50 or less | 4.20 | 4.8 | Aluminum | Clean and dry |
| TMAL-M3-20-PLN | Metric | M3 x 0.5 | 20 | 1.00 | 4.22 | 6.0 | HRB 50 or less | 4.20 | 4.8 | Aluminum | Clean and dry |
| TMAL-M3-22-PLN | Metric | M3 x 0.5 | 22 | 1.00 | 4.22 | 6.0 | HRB 50 or less | 4.20 | 4.8 | Aluminum | Clean and dry |
| TMAL-M3-25-PLN | Metric | M3 x 0.5 | 25 | 1.00 | 4.22 | 6.0 | HRB 50 or less | 4.20 | 4.8 | Aluminum | Clean and dry |
| TMAL-3.5M3-6-PLN | Metric | M3 x 0.5 | 6 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMAL-3.5M3-8-PLN | Metric | M3 x 0.5 | 8 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMAL-3.5M3-10-PLN | Metric | M3 x 0.5 | 10 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMAL-3.5M3-12-PLN | Metric | M3 x 0.5 | 12 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMAL-3.5M3-14-PLN | Metric | M3 x 0.5 | 14 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMAL-3.5M3-16-PLN | Metric | M3 x 0.5 | 16 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMAL-3.5M3-18-PLN | Metric | M3 x 0.5 | 18 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMAL-3.5M3-20-PLN | Metric | M3 x 0.5 | 20 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMAL-3.5M3-22-PLN | Metric | M3 x 0.5 | 22 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMAL-3.5M3-25-PLN | Metric | M3 x 0.5 | 25 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMS4-M3.5-6-P | Metric | M3.5 x 0.6 | 6 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M3.5-8-P | Metric | M3.5 x 0.6 | 8 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M3.5-10-P | Metric | M3.5 x 0.6 | 10 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M3.5-12-P | Metric | M3.5 x 0.6 | 12 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M3.5-14-P | Metric | M3.5 x 0.6 | 14 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M3.5-16-P | Metric | M3.5 x 0.6 | 16 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M3.5-18-P | Metric | M3.5 x 0.6 | 18 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M3.5-20-P | Metric | M3.5 x 0.6 | 20 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M3.5-22-P | Metric | M3.5 x 0.6 | 22 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M3.5-25-P | Metric | M3.5 x 0.6 | 25 | 1.00 | 5.41 | 6.8 | HRB 88 or less | 5.39 | 6.4 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMST-M3.5-6-Z | Metric | M3.5 x 0.6 | 6 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M3.5-8-Z | Metric | M3.5 x 0.6 | 8 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M3.5-10-Z | Metric | M3.5 x 0.6 | 10 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M3.5-12-Z | Metric | M3.5 x 0.6 | 12 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M3.5-14-Z | Metric | M3.5 x 0.6 | 14 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M3.5-16-Z | Metric | M3.5 x 0.6 | 16 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M3.5-18-Z | Metric | M3.5 x 0.6 | 18 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M3.5-20-Z | Metric | M3.5 x 0.6 | 20 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M3.5-22-Z | Metric | M3.5 x 0.6 | 22 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M3.5-25-Z | Metric | M3.5 x 0.6 | 25 | 1.00 | 5.41 | 6.8 | HRB 80 or less | 5.39 | 6.4 | Heat treated carbon steel | Zinc with clear chromate |
| TMSS-M3.5-6-P | Metric | M3.5 x 0.6 | 6 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M3.5-8-P | Metric | M3.5 x 0.6 | 8 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M3.5-10-P | Metric | M3.5 x 0.6 | 10 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M3.5-12-P | Metric | M3.5 x 0.6 | 12 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M3.5-14-P | Metric | M3.5 x 0.6 | 14 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M3.5-16-P | Metric | M3.5 x 0.6 | 16 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M3.5-18-P | Metric | M3.5 x 0.6 | 18 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M3.5-20-P | Metric | M3.5 x 0.6 | 20 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M3.5-22-P | Metric | M3.5 x 0.6 | 22 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M3.5-25-P | Metric | M3.5 x 0.6 | 25 | 1.00 | 5.41 | 6.8 | HRB 70 or less | 5.39 | 6.4 | 300-Series stainless steel | Passivated and/or tested |
| TMAL-M3.5-6-PLN | Metric | M3.5 x 0.6 | 6 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMAL-M3.5-8-PLN | Metric | M3.5 x 0.6 | 8 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMAL-M3.5-10-PLN | Metric | M3.5 x 0.6 | 10 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMAL-M3.5-12-PLN | Metric | M3.5 x 0.6 | 12 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMAL-M3.5-14-PLN | Metric | M3.5 x 0.6 | 14 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMAL-M3.5-16-PLN | Metric | M3.5 x 0.6 | 16 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMAL-M3.5-18-PLN | Metric | M3.5 x 0.6 | 18 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMAL-M3.5-20-PLN | Metric | M3.5 x 0.6 | 20 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMAL-M3.5-22-PLN | Metric | M3.5 x 0.6 | 22 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMAL-M3.5-25-PLN | Metric | M3.5 x 0.6 | 25 | 1.00 | 5.41 | 6.8 | HRB 50 or less | 5.39 | 6.4 | Aluminum | Clean and dry |
| TMS4-M4-6-P | Metric | M4 x 0.7 | 6 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M4-8-P | Metric | M4 x 0.7 | 8 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M4-10-P | Metric | M4 x 0.7 | 10 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M4-12-P | Metric | M4 x 0.7 | 12 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M4-14-P | Metric | M4 x 0.7 | 14 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M4-16-P | Metric | M4 x 0.7 | 16 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M4-18-P | Metric | M4 x 0.7 | 18 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M4-20-P | Metric | M4 x 0.7 | 20 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M4-22-P | Metric | M4 x 0.7 | 22 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M4-25-P | Metric | M4 x 0.7 | 25 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMST-M4-6-Z | Metric | M4 x 0.7 | 6 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M4-8-Z | Metric | M4 x 0.7 | 8 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M4-10-Z | Metric | M4 x 0.7 | 10 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M4-12-Z | Metric | M4 x 0.7 | 12 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M4-14-Z | Metric | M4 x 0.7 | 14 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M4-16-Z | Metric | M4 x 0.7 | 16 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M4-18-Z | Metric | M4 x 0.7 | 18 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M4-20-Z | Metric | M4 x 0.7 | 20 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M4-22-Z | Metric | M4 x 0.7 | 22 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M4-25-Z | Metric | M4 x 0.7 | 25 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMSS-M4-6-P | Metric | M4 x 0.7 | 6 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M4-8-P | Metric | M4 x 0.7 | 8 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M4-10-P | Metric | M4 x 0.7 | 10 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M4-12-P | Metric | M4 x 0.7 | 12 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M4-14-P | Metric | M4 x 0.7 | 14 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M4-16-P | Metric | M4 x 0.7 | 16 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M4-18-P | Metric | M4 x 0.7 | 18 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M4-20-P | Metric | M4 x 0.7 | 20 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M4-22-P | Metric | M4 x 0.7 | 22 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M4-25-P | Metric | M4 x 0.7 | 25 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMAL-M4-6-PLN | Metric | M4 x 0.7 | 6 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMAL-M4-8-PLN | Metric | M4 x 0.7 | 8 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMAL-M4-10-PLN | Metric | M4 x 0.7 | 10 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMAL-M4-12-PLN | Metric | M4 x 0.7 | 12 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMAL-M4-14-PLN | Metric | M4 x 0.7 | 14 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMAL-M4-16-PLN | Metric | M4 x 0.7 | 16 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMAL-M4-18-PLN | Metric | M4 x 0.7 | 18 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMAL-M4-20-PLN | Metric | M4 x 0.7 | 20 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMAL-M4-22-PLN | Metric | M4 x 0.7 | 22 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMAL-M4-25-PLN | Metric | M4 x 0.7 | 25 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMS4-M5-6-P | Metric | M5 x 0.8 | 6 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M5-8-P | Metric | M5 x 0.8 | 8 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M5-10-P | Metric | M5 x 0.8 | 10 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M5-12-P | Metric | M5 x 0.8 | 12 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M5-14-P | Metric | M5 x 0.8 | 14 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M5-16-P | Metric | M5 x 0.8 | 16 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M5-18-P | Metric | M5 x 0.8 | 18 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M5-20-P | Metric | M5 x 0.8 | 20 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M5-22-P | Metric | M5 x 0.8 | 22 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMS4-M5-25-P | Metric | M5 x 0.8 | 25 | 1.27 | 7.14 | 8.0 | HRB 88 or less | 7.12 | 7.9 | 400-Series heat treated stainless steel | Passivated and/or tested |
| TMST-M5-6-Z | Metric | M5 x 0.8 | 6 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M5-8-Z | Metric | M5 x 0.8 | 8 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M5-10-Z | Metric | M5 x 0.8 | 10 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M5-12-Z | Metric | M5 x 0.8 | 12 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M5-14-Z | Metric | M5 x 0.8 | 14 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M5-16-Z | Metric | M5 x 0.8 | 16 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M5-18-Z | Metric | M5 x 0.8 | 18 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M5-20-Z | Metric | M5 x 0.8 | 20 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M5-22-Z | Metric | M5 x 0.8 | 22 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMST-M5-25-Z | Metric | M5 x 0.8 | 25 | 1.27 | 7.14 | 8.0 | HRB 80 or less | 7.12 | 7.9 | Heat treated carbon steel | Zinc with clear chromate |
| TMSS-M5-6-P | Metric | M5 x 0.8 | 6 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M5-8-P | Metric | M5 x 0.8 | 8 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M5-10-P | Metric | M5 x 0.8 | 10 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M5-12-P | Metric | M5 x 0.8 | 12 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M5-14-P | Metric | M5 x 0.8 | 14 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M5-16-P | Metric | M5 x 0.8 | 16 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M5-18-P | Metric | M5 x 0.8 | 18 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M5-20-P | Metric | M5 x 0.8 | 20 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M5-22-P | Metric | M5 x 0.8 | 22 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMSS-M5-25-P | Metric | M5 x 0.8 | 25 | 1.27 | 7.14 | 8.0 | HRB 70 or less | 7.12 | 7.9 | 300-Series stainless steel | Passivated and/or tested |
| TMAL-M5-6-PLN | Metric | M5 x 0.8 | 6 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMAL-M5-8-PLN | Metric | M5 x 0.8 | 8 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMAL-M5-10-PLN | Metric | M5 x 0.8 | 10 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMAL-M5-12-PLN | Metric | M5 x 0.8 | 12 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMAL-M5-14-PLN | Metric | M5 x 0.8 | 14 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMAL-M5-16-PLN | Metric | M5 x 0.8 | 16 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMAL-M5-18-PLN | Metric | M5 x 0.8 | 18 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMAL-M5-20-PLN | Metric | M5 x 0.8 | 20 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMAL-M5-22-PLN | Metric | M5 x 0.8 | 22 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
| TMAL-M5-25-PLN | Metric | M5 x 0.8 | 25 | 1.27 | 7.14 | 8.0 | HRB 50 or less | 7.12 | 7.9 | Aluminum | Clean and dry |
